| Name | XR-H5MD |
|---|---|
| Manufacturer | Aiwa |
| Released | 1997/07 |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 260 (width) x 341 (height) x 342 (depth) mm |
| Weight | 7600 |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | Not recorded |
| Voltage | 100 |
| Power cable | Not recorded |
| Price (launch) | Not recorded |
| ¥79 800 | |
| - | |
| Inputs | 3.5mm line in (analog-only), 3.5mm microphone, CD, Radio recording, Tape deck |
| Outputs | 3.5mm headphone, Digital optical (TOSLINK) |
| Control | Not recorded |
A monaural recording mode that allows long-term recording of up to 148 minutes on a 74-minute MD 2x fast playback for efficient listening Easy character input with the jog dial (up to 50 characters per song including katakana, alphanumeric characters, and symbols can be input) Auto mark to automatically mark the beginning, time mark to be added every 5 minutes, manual mark function to be added wherever you like All songs / 1 song direct recording
Full karaoke function You can enjoy karaoke with MD, CD, etc. in the background. It has a full range of karaoke functions, including microphone mixing (recording and playback) with digital echo, two microphone terminals for duets, an auto vocal fader, and an auto multiplex compatible with multi-tone karaoke software.
FM wideband 76-108MHz
Content adapted from: Aiwa Press Release Aiwa Press Release (MiniDisc Wiki mirror) Aiwa Product Page Aiwa Product Page (MiniDisc Wiki mirror)
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email..
Additional specifications and references
| Scms | Yes |
|---|---|
| Web Md | No (not NetMD) |
| Manual | |
| Region | Japan |
