Aiwa XR-MD500
| Name | XR-MD500 |
|---|---|
| Manufacturer | Aiwa |
| Released | 1999/05 |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 180 W x 290 H x 340 D (mm) |
| Weight | 7.7Kg |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | No |
| Voltage | 100 |
| Power cable | AC |
| Price (launch) | Not recorded |
| ¥65 000 | |
| - | |
| Inputs | RCA in, CD |
| Outputs | 3.5mm headphone, Speaker amplifier |
| Control | Not recorded |
Features: 3-MD changer, 3-CD changer, single cassette deck, tuner. Single hit recording function, MD/cassette simultaneous REC key can record from CD to both MD and cassette at the same time, Weekly timer recording for three programs, Double-speed playback function, Flexible CD/MD playback: program, random (all/one CDs or MDs), repeat (all/one CD or MDs/one track)
Specs: 60W high-power amplifier (30W+30W), FM 76-108 Mhz, 13cm woofer, 6cm tweeter, power source 100VAC.
Content adapted from: Minidisc.org Page, Aiwa product page (Archived)
Manuals
Repair
Photos
Source attachment — unavailable in this snapshot Have photos or data to add? Edit the page! We do not accept contributions via email..
Additional specifications and references
| Web Md | No |
|---|---|
| Manual | |
| Region | Japan |
