Aiwa AM-HX3

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2024-01-01

Manufacturer
Aiwa
Model / source grouping
AM-HX3
Device type
portable
MDLP modes
No
NetMD interface
No
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

No directly linked document has been identified for this record. Search the manual library or consult the source below.

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Aiwa AM-HX3”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name AM-HX3
Manufacturer Aiwa
Released 1998/07
Device type portable
Recorder Player
MDLP No
NetMD No
Hi-MD No
Radio No
Dimensions 97W x 77.6H x 21.6D (mm)
Weight 208g (including rechargeable battery), 178g (main unit)
ATRAC ver Not recorded
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) 3xAA
Voltage 3.6
Power cable Not recorded
Price (launch) Not recorded
¥32 800
-
Inputs Not recorded
Outputs 3.5mm headphone
Control Not recorded

Features: Jog dial for track selection, double speed playback mode, backlit remote. Program (up to 25 tracks), repeat 1, repeat all, and shuffle play modes. Silicon rubber cushions on ear caps for better fit and bass reproduction. 1 bit D/A. Battery life: Rechargeable LiIon: 7 hr, AAx3: 19 hr, both: 26 hr. Recharge time: 2hr.

Specs: Headphone amp: 10mW+10mW

Content adapted from: Minidisc.org page, Aiwa press release

Manuals

Repair

(repair links go here)

Photos

Have photos or data to add? Edit the page! We do not accept contributions via email..

Additional specifications and references
Web MdNo
Manual
RegionJapan
