Adapted from “Aiwa AM-NX9”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.
| Name | AM-NX9 |
|---|---|
| Manufacturer | Aiwa |
| Released | 2003/04 |
| Device type | portable |
| Recorder | Recorder |
| MDLP | Yes |
| NetMD | Yes |
| Hi-MD | No |
| Radio | Not recorded |
| Dimensions | 81.6 × 29.9 × 75.0 mm |
| Weight | 104g |
| ATRAC ver | Type-S |
| Battery | Not recorded AA |
| Battery notes | Not recorded |
| Sidecar (depr) | No |
| Voltage | 3 |
| Power cable | Center positive |
| Price (launch) | Not recorded |
| Not recorded | |
| - | |
| Inputs | Not recorded |
| Outputs | 3.5mm headphone |
| Control | USB Mini-B |
Content adapted from: Minidisc.org page
Manuals
Repair
(repair links go here)
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email..
Additional specifications and references
| Web Md | Supported (Type-S exploits) |
|---|---|
| Manual | User manual, Service manual |
| Region |
