Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.
Attribution and changes
Adapted from “Clarion MAX620VD”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.
| Name | MAX620VD |
|---|---|
| Manufacturer | Clarion |
| Released | 2002/05 |
| Device type | auto |
| Recorder | Player |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 178 (W) x 100 (H) × 181 (D) |
| Weight | 3100 |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | Not recorded |
| Voltage | 12 |
| Power cable | Not recorded |
| Price (launch) | Not recorded |
| ¥293 000 | |
| - | |
| Inputs | CD |
| Outputs | Not recorded |
| Control | Not recorded |
◎ LCD monitor / screen dimensions: 6.5 type (143 × 79? O) -Drive method: TFT active matrix -Number of pixels: 280,800 pixels (234 x 400 x 3)
◎ MD player section -Frequency characteristics: 20Hz to 20kHz (± 2dB) -SN ratio: 90dB -Separation: 80dB -High frequency distortion: 0.01 %
◎ Audio section ・ Rated output: 17W x 4 (20Hz to 20kHz, 1%, 4Ω) ・ Maximum output: 40W x 4
Content adapted from: Clarion Press Release Clarion Press Release (MiniDisc Wiki mirror) av.watch geocities geocities (MiniDisc Wiki mirror) - No MDLP?
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email.
Additional specifications and references
| Web Md | No (not NetMD) |
|---|---|
| Manual | |
| Region | Japan |
