Hitachi 570C5SYA

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2024-07-19

Manufacturer
Hitachi
Model / source grouping
570C5SYA
Device type
misc
MDLP modes
Yes
NetMD interface
Yes
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

No directly linked document has been identified for this record. Search the manual library or consult the source below.

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Hitachi 570C5SYA”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name 570C5SYA
Manufacturer Hitachi
Released 2002/05
Device type misc
Recorder Recorder
MDLP Yes
NetMD Yes
Hi-MD No
Radio Not recorded
Dimensions W 105 x D 339 x H 367 mm
Weight 8600
ATRAC ver Not recorded
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) Not recorded
Voltage 100
Power cable Not recorded
Price (launch) Not recorded
Not recorded
-
Inputs 3.5mm line in (analog-only), 3.5mm microphone, CD
Outputs 3.5mm line out (analog-only)
Control Not recorded

Prius Deck 570C 570C5SYA

  • CPU: Athlon XP 1600+
  • Chipset: SiS740
  • Memory standard: 256MB / maximum: 1024MB
  • Video: memory Built-in chipset / 16MB (shared with main memory)
  • Sound: AC97 compliant
  • Hard disk drive: 60GB / Ultra ATA 100
  • Other auxiliary storage devices:
  • CD-R / RW & DVD-ROM combo drive
  • Net MD compatible MD drive
  • USB x 7, IEEE1394 x 2, PC card slot (Type III x 1, CardBus compatible)
  • network: 10BASE-T / 100BASE-TX Ethernet, modem (data: maximum 56kbps / V.90 standard compliant, FAX: maximum 14.4kbps)

Display: 15 inch super pure color LCD
Maximum resolution: 1024 x 768 pixels
Maximum display color: 16.77 million colors
OS: Windows XP Home Edition
Size: 105 x 339 x 367 mm (W x D x H) (when placed vertically, excluding stand and protrusions)
Weight: About 8.6kg

Content adapted from: Product Page Another Product Page it media The MD Drive bezel looks similar to one from Kenwood
