Kenwood DPX-055MD

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2024-01-01

Manufacturer
Kenwood
Model / source grouping
DPX-055MD
Device type
auto
MDLP modes
Yes
NetMD interface
No
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Kenwood DPX-055MD”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name DPX-055MD
Manufacturer Kenwood
Released 2005/12
Device type auto
Recorder Player
MDLP Yes
NetMD No
Hi-MD No
Radio Yes
Dimensions 2-DIN 178W × 100H × 155Dmm
Weight 1900
ATRAC ver Not recorded
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) Not recorded
Voltage 12
Power cable Not recorded
Price (launch) Not recorded
¥39 900
-
Inputs 3.5mm line in (analog-only), CD
Outputs Not recorded
Control Not recorded

Kenwood DPX-055MD / DPX-055MDS

Equipped with SRS WOW - a completely new audio processor that combines the three technologies of "SRS 3D", "SRS TruBass" and "SRS FOCUS". "SRS 3D" builds a natural surround space without discomfort anywhere in the vehicle, and "SRS TruBass" realizes powerful deep bass reproduction that does not depend on the speaker's playback capacity. "SRS FOCUS" creates an ideal sound field space on the dashboard regardless of where the speakers are installed. By fusing these three technologies, we solve problems such as sound muffled and sound image localization, and create an ideal vehicle interior space where every seat is in the best position for sound.

[MD part]

  • ・Frequency characteristics 20Hz - 20kHz (±1dB) ・S/N ratio 90dB (1kHz) ・Dynamic range 90dB

[CD part]

  • ・Frequency characteristics 10Hz - 20kHz (±1dB) ・S/N ratio 105dB (1kHz)・Dynamic range 93dB

[FM section]

  • Receiving frequency range 76.0MHz - 90.0MHz (100kHz steps)
  • Practical sensitivity 9.3dBf (0.8μV/75Ω)
  • Frequency characteristics 30Hz - 15kHz (±3.0dB)
  • Stereo separation 30dB (1kHz) )

[AM section]

  • Receiving frequency range 522kHz to 1629kHz (9kHz steps)
  • Sensitivity 28dBμ 17.5 kHz
  • Variable range ±12 dB

[Audio part]

  • Maximum output 50 W x 4
  • Rated output 30 W x 4 (4 Ω, 1 kHz, 10% THD) [Common part]
  • Power supply voltage 14.4 V (11 to 16 V)
  • Maximum current consumption 10A
  • Embedded dimensions 178W×100H×155Dmm
  • Weight 1.9kg

Content adapted from: Kenwood Press Release Kenwood Press Release (MiniDisc Wiki mirror) av.watch

Manuals

Kenwood DPX-055MD User Manual JP

Repair

Photos

Have photos or data to add? Edit the page! We do not accept contributions via email.

Additional specifications and references
Web MdNo (not NetMD)
ManualUser manual
RegionJapan
