Device

Kenwood KMD-300

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2024-01-01

Manufacturer
Kenwood
Model / source grouping
KMD-300
Device type
auto
MDLP modes
Yes
NetMD interface
No
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

Accessories & internal parts

Source-referenced components. Check conditions before substituting parts.

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Kenwood KMD-300”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name KMD-300
Manufacturer Kenwood
Released Not recorded
Device type auto
Recorder Player
MDLP Yes
NetMD No
Hi-MD No
Radio No
Dimensions Not recorded
Weight 1400
ATRAC ver Not recorded
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) Not recorded
Voltage 12
Power cable Not recorded
Price (launch) Not recorded
Not recorded
-
Inputs Not recorded
Outputs Not recorded
Control Not recorded

Found in an Audi A8 2007 model. The Service Manual has a copyright 2003.

The KMD-300 / GD2 (Audi part# 4E0 035 121 41 ) most likely uses the MOST Bus, a daisy-chain topology or ring topology and synchronous data communication to transport audio, video, voice and data signals via plastic optical fiber (POF) (MOST25, MOST150). Harman Becker Automotive Systems manufactures the MMI system for Audi, utilizing QNX Neutrino's Real Time Operating System (RTOS) software. The Service Manual has a tremendous amount of detail.

System Chipset: CXA2523AR ATRAC Chipset: CXD2667R

Manuals

Kenwood KMD-300 / GD2 Service Manual ENG

Repair

Photos

Have photos or data to add? Edit the page! We do not accept contributions via email.

Additional specifications and references
Web MdNo
ManualService manual
RegionJapan
