| Name | NDL-100MD |
|---|---|
| Manufacturer | Kenwood |
| Released | 2007/03 |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | Yes |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 180 x 215 x 326mm |
| Weight | 5.0kg (main unit) |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | No |
| Voltage | 100 |
| Power cable | AC |
| Price (launch) | Not recorded |
| ¥43 000 | |
| - | |
| Inputs | 3.5mm line in (analog-only), CD |
| Outputs | 3.5mm line out (analog-only), 3.5mm headphone, Speaker amplifier, other |
| Control | USB Type-B |
Available in NDL-100MD-S (silver) and NDL-100MD-W (white). Sometimes labeled RMD-NDL100MD
CD→MD 4x speed
Equipped with "D.AUDIO" input/output terminals for portable audio devices, it supports analog input and analog output from other audio devices.
Practical maximum output: 15W+15W (JEITA 6Ω)
Input terminal (sensitivity/impedance): 240mV/20kΩ(D.AUDIO)
Output terminal (sensitivity/impedance): 450mV/10Ω(D.AUDIO Low)
Content adapted from: Kenwood Press Release av.watch Kenwood Product Page
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email.
Additional specifications and references
| Scms | Yes |
|---|---|
| Web Md | No (not NetMD) |
| Export | Yes |
| Manual | User manual |
| Region | Japan |
