Device

Kenwood XM-7MD

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2024-01-01

Manufacturer
Kenwood
Model / source grouping
XM-7MD
Device type
bookshelf
MDLP modes
No
NetMD interface
No
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

No directly linked document has been identified for this record. Search the manual library or consult the source below.

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Kenwood XM-7MD”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name XM-7MD
Manufacturer Kenwood
Released 1997/08
Device type bookshelf
Recorder Recorder
MDLP No
NetMD No
Hi-MD No
Radio Yes
Dimensions (MD) W270 x H124 x D332mm (amp) W 270 x H 104 x D 343mm
Weight (MD) 3.1kg (amp) 4.9kg
ATRAC ver 4
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) Not recorded
Voltage Not recorded
Power cable Not recorded
Price (launch) Not recorded
¥199 800
-
Inputs Digital optical (TOSLINK), CD, Radio recording
Outputs Speaker amplifier
Control Not recorded

Features: Includes 2 MD drives and 6 CD changer. ATRAC 4.0, 20 bit D/A and A/D. On touch MD to MD copying, in analog, with titles copied simultaneously. One CD can be copied to two MDs simultaneously. Can record from CD to one MD drive while simultaneously recording from tuner or aux input to the other MD drive. Relay recording can record one whole MD then continue recording on the MD in the other drive. Kanji titling and display. Kenwood's D.R.I.V.E. circuitry. Japanese domestic tuner (76MHz to 90MHz). Optional cyber titler keyboard, plugs into unit and also prints labels. Sampling rate converter. New "quick move" and "quick erase" editing functions allow you to select an entire set of tracks to be moved to a new spot, or erased. 'New Preview' function (?).

Content adapted from: Kenwood Press Release Kenwood Press Release (MiniDisc Wiki mirror) Minidisc.org Summary

Manuals

Repair

Photos

Have photos or data to add? Edit the page! We do not accept contributions via email..

Additional specifications and references
Manual
RegionJapan
