| Name | FR-X9A |
|---|---|
| Manufacturer | Onkyo |
| Released | 2003/03 |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | Yes |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 205(W)×154(H)×354(D) mm |
| Weight | 5.7kg |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | Not recorded |
| Voltage | 100 |
| Power cable | AC |
| Price (launch) | Not recorded |
| ¥55 000 | |
| - | |
| Inputs | RCA in, Digital optical (TOSLINK), CD |
| Outputs | 3.5mm headphone, RCA out, Digital optical (TOSLINK) |
| Control | Not recorded |
FR-SX9A = system with speakers: MSRP 75,000 Yen
FR-X9A = just the main CD/MD/AMP: MSRP 55,000 Yen
- Practical maximum output: 26 W + 26 W (4 Ω EIAJ)
- Rated output: 19 W + 19 W (4 Ω), 16 W + 16 W (6 Ω))
- Input sensitivity/input impedance: 150mV/50kΩ (LINE, TAPE, CDR)
- Power consumption: 55 W
FM: 76.0～108.0MHz
Content adapted from: Onkyo Press Release Onkyo Press Release (MiniDisc Wiki mirror) av.watch
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email.
Additional specifications and references
| Scms | Yes |
|---|---|
| Web Md | No (not NetMD) |
| Manual | User manual |
| Region | Japan |
