MiniDisc CentralSearch

Device

Panasonic RX-MDX83

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2022-08-15

Manufacturer
Panasonic
Model / source grouping
RX-MDX83
Device type
boombox
MDLP modes
Yes
NetMD interface
No
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Panasonic RX-MDX83”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name RX-MDX83
Manufacturer Panasonic
Released 2008/10
Device type boombox
Recorder Recorder
MDLP Yes
NetMD No
Hi-MD No
Radio Yes
Dimensions 431 x 272 x 180 mm
Weight 4800
ATRAC ver Not recorded
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) Not recorded
Voltage 100
Power cable Not recorded
Price (launch) Not recorded
¥35 000
-
Inputs CD, Tape deck
Outputs 3.5mm line out (analog-only)
Control Not recorded

RX-MDX83 is equipped with a cassette in addition to a CD / MD. The body color is silver (-S) only. The operation buttons are centrally located on the foot stand, and a "pop-up operation stage" that changes to an easy-to-operate angle in conjunction with the angle of the main body is installed to improve operability. The operation panel and remote control are displayed in Japanese to improve usability.

MD is compatible with MDLP, and up to 6x speed recording from CD to MD is possible. It also has an MD group management function and a title search. The input terminal is equipped with P-MD, analog audio, and microphone input (monaural).

The maximum practical output is 3W x 2ch. A 7 cm diameter PP mica speaker is used as the speaker to achieve rich bass and transparent treble reproduction. It is also equipped with a "live virtualizer" that enhances the feeling of live performance. It also has a headphone output. A remote control is attached.

Content adapted from: AV.Watch Panasonic Product Page Panasonic Press Release Panasonic Press Release (MiniDisc Wiki mirror)

Manuals

Panasonic RX-MDX83 Manual Japanese

Repair

Photos

Have photos or data to add? Edit the page! We do not accept contributions via email.

Additional specifications and references
Web MdNo
ManualUser manual
RegionJapan
