| Name | AVIC-XM520 |
|---|---|
| Manufacturer | Pioneer |
| Released | 1999/11 |
| Device type | auto |
| Recorder | Not recorded |
| MDLP | Not recorded |
| NetMD | Not recorded |
| Hi-MD | Not recorded |
| Radio | Yes |
| Dimensions | 178 (W) x 100 (H) x 165 (D) mm |
| Weight | 3000 |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | Not recorded |
| Voltage | 12 |
| Power cable | Not recorded |
| Price (launch) | Not recorded |
| ¥248 000 | |
| - | |
| Inputs | CD |
| Outputs | Not recorded |
| Control | Not recorded |
Pioneer Carrozzeria AVIC-XM520
MD player part Frequency characteristic
- 5 to 20,000Hz one
- S / N ratio 90dB (1kHz) (IHF-A network)
- Dynamic lens 91dB (1kHz)
Amplifier section
- Maximum output 35W x 4
Monitor
- Screen size 6.5 inch wide
- Number of pixels 280,800 pixels (234 x 1,200)
- method TFT active matrix method, transparent type
Content adapted from: Pioneer Carrozzeria AVIC-XM520
Manuals
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email.
Additional specifications and references
| Manual | |
|---|---|
| Region | Japan |
