Pioneer FH-P055M

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2022-12-06

Manufacturer
Pioneer
Model / source grouping
FH-P055M
Device type
auto
MDLP modes
Yes
NetMD interface
No
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Pioneer FH-P055M”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name FH-P055M
Manufacturer Pioneer
Released 2004/02
Device type auto
Recorder Player
MDLP Yes
NetMD No
Hi-MD No
Radio Yes
Dimensions Mounting dimensions: 178 (W) x 100 (H) x 160 (D) mm
Weight 1.8kg
ATRAC ver Not recorded
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) Not recorded
Voltage 12
Power cable Not recorded
Price (launch) $410
¥46 200
-
Inputs RCA in, CD
Outputs Not recorded
Control Remote (Sony)

Carrozzeria branded auto unit.

Amplifier section - maximum output: 50W x 4

Audio section

  • subwoofer output (RCA):
  • <Cutoff frequency> 50/63/80/100 / 125Hz
  • <Cutoff slope> -18dB, -12dB / oct
  • <Adjustment range> + 6 to -24dB
  • <Phase> NOR / REV

high pass filter (front / rear independent):

  • <Cutoff frequency> 50/63/80/100 / 125Hz
  • <Cutoff slope> -12dB, -6dB / oct

9-band graphic equalizer:

  • <Frequency> 50/100/200/400/800 / 1.6k / 3.15k / 6.3k / 12.5kHz
  • <Adjustment range> ± 12dB
  • Loudness ( Volume: -30dB): 10dB (100Hz), 7dB (10kHz)
  • Pre-out maximum output level: 1.8V / 1kΩ

CD player

  • frequency characteristics: 5 to 20,000Hz (± 1dB)
  • SN ratio: 94dB (1kHz) (IHF-A) network)
  • Dynamic range: 92dB

MD player

  • frequency characteristics: 20 to 20,000Hz (± 1dB)
  • SN ratio: 90dB (1kHz) (IHF-A network)
  • Dynamic range: 90dB

Tuner FM / AM

  • practical sensitivity:
  • FM / 8dBf (0.7μV / 75Ω, MONO, SN ratio: 30dB)
  • AM / 18μV (SN ratio: 20dB)

Pioneer Press Release 1 Pioneer Press Release 2 Pioneer Press Release 2 (MiniDisc Wiki mirror) Pioneer product page av.watch

Manuals

User manual

Installation manual

Photos

Video

Watch the referenced video on YouTube

Additional specifications and references
ManualUser manual, other
RegionJapan
