| Name | MEH-P515 |
|---|---|
| Manufacturer | Pioneer |
| Released | 2002/02 |
| Device type | auto |
| Recorder | Player |
| MDLP | Yes |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 178 x 50 x 162 |
| Weight | 1100 |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | No |
| Voltage | 12 |
| Power cable | Not recorded |
| Price (launch) | Not recorded |
| ¥39 800 | |
| - | |
| Inputs | Not recorded |
| Outputs | RCA out, Speaker amplifier |
| Control | Not recorded |
- "MD-auto gain control" adjusts track volumes so that large differences do not occur between tracks.
- 3-band parametric equalizer adjustable from -12dB to +12dB.
- Selectable subwoofer cutoff frequencies (50, 80, 125Hz), slope fixed at -18dB/octave.
- Amp: 50Wx4 + 70Wx1 (subwoofer) SNR > 94dB, Dyn. Range > 92dB, FM: 76.1-89.9MHz
Content adapted from: Pioneer Press Release 1 Pioneer Press Release 2 Pioneer Press Release 2 (MiniDisc Wiki mirror) Minidisc.org page
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email..
Additional specifications and references
| Manual | User manual |
|---|---|
| Region | Japan |
