| Name | MD-α77 |
|---|---|
| Manufacturer | Sansui |
| Released | 1995/01 |
| Device type | deck |
| Recorder | Recorder |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | No |
| Dimensions | Width 284 x Height 90 x Depth 300 mm |
| Weight | 2.9kg |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | Not recorded |
| Voltage | 100 |
| Power cable | Not recorded |
| Price (launch) | Not recorded |
| ¥85 000 | |
| - | |
| Inputs | RCA in, Digital optical (TOSLINK), Digital coaxial |
| Outputs | RCA out, Digital optical (TOSLINK) |
| Control | Not recorded |
The correct model name is MD-α77 - but no one can type or pronounce "α"
Frequency characteristic 5Hz-20kHz, ± 0.3dB
External dimensions Width 284 x Height 90 x Depth 300 mm
SN ratio 96 dB or more (during playback)
weight 2.9kg
Content adapted from: @@Source title@@
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email.
Additional specifications and references
| Scms | Yes |
|---|---|
| Web Md | No |
| Manual | |
| Region | Japan |
