Device

Sharp MD-X60

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2024-10-12

Manufacturer
Sharp
Model / source grouping
MD-X60
Device type
bookshelf
MDLP modes
No
NetMD interface
No
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Sharp MD-X60”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name MD-X60
Manufacturer Sharp
Released 1998/03
Device type bookshelf
Recorder Recorder
MDLP No
NetMD No
Hi-MD No
Radio Yes - 88-108MHz
Dimensions 240 (width) x 332 (height) x 325 (depth) mm
Weight 8600
ATRAC ver Not recorded
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) No
Voltage 120, 230
Power cable AC
Price (launch) Not recorded
¥76 000
-
Inputs 3.5mm line in (analog-only), RCA in, Digital optical (TOSLINK), Tape deck
Outputs 3.5mm headphone, RCA out, Speaker amplifier, Tape deck
Control Not recorded

MD-X60 (North America/Mexico), MD-X60H (Europe/Asia/Middle East)

  1. CD→MD 2) MD→MD 3) TAPE→MD 4) CD→TAPE 5) MD→TAPE 5 types of "one-shot edit buttons" for easy editing between MD, CD, and cassette
  2. Simultaneous editing of sound and text from MD to MD (using our portable MD and optional connection cable)
  3. "Digital input terminal" that can record Internet distribution music to MD (connected to optional sound card)
  4. Equipped with a "sampling rate converter" that supports digital recording of expanding CS/BS music broadcasts
  5. "Large 4-color FL display" with spectrum analyzer that is fun to look at

Optical Pickup: RCTRH8173AFZZ
ATRAC IC: LR376481

Content adapted from: Sharp Press Release Sharp Press Release (MiniDisc Wiki mirror) Sharp Product Page Sharp Product Page (MiniDisc Wiki mirror) Sharp Specs Page Sharp Specs Page (MiniDisc Wiki mirror)

Manuals

Sharp MD-X60 User Manual

Sharp MD-X60 Service Manual

Repair

Photos

Have photos or data to add? Edit the page! We do not accept contributions via email.

Additional specifications and references
ScmsYes
Web MdNo (not NetMD)
ExportNo
Remote Page
Atrac Iclr376481
ManualUser manual, Service manual
RegionJapan, Europe
