| Name | SD-CX80 |
|---|---|
| Manufacturer | Sharp |
| Released | Not recorded |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | Yes |
| NetMD | Not recorded |
| Hi-MD | Not recorded |
| Radio | Yes |
| Dimensions | 318 (width) x 209 ( Height) x 210 (depth) mm |
| Weight | 4600 |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | Not recorded |
| Voltage | 100 |
| Power cable | Not recorded |
| Price (launch) | Not recorded |
| Not recorded | |
| - | |
| Inputs | RCA in, CD |
| Outputs | 3.5mm headphone |
| Control | Not recorded |
Sharp SD-CX80
Compact disc player part format: Compact disc digital audio system Reading method: Non-contact optical reading method (using semiconductor laser) Number of channels: Stereo 2 channels Frequency characteristics: 20 to 20,000Hz (+ 1 / -3dB) (JEITA) * Wow・ Flutter… Measurement limit (± 0.001% W.PEAK) or less (JEITA) * Tuner section Reception frequency: FM: 76.0 to 108.0MHz (TV audio 1 to 3CH) AM: 522 to 1,629 kHz Circuit method: Quartz digital synthesizer method Super heterodyne FM / AM tuner Antenna: FM (far / near), AM, earth Amplifier / Common part Practical maximum output… 40W (20W + 20W) (JEITA) * A / D noise shaping… 7th order ΔΣ (delta sigma) modulation input terminal… Analog external input: 500mV (47kΩ) Pin jack (L / R) × 1 Output terminal: Speaker output: 4Ω Headphone output: 16 to 50Ω (recommended 32Ω) Diameter 3.5mm stereo mini jack x 1 Power supply: 100V AC, 50/60 Hz Power consumption: AC 48W Maximum external dimensions: 318 (width) x 209 ( Height) x 210 (depth) mm (JEITA) * Weight: Approximately 4.6 kg Speaker part type… Bass reflex type (speaker net removable type) Speaker… Woofer: 12cm Tweeter: 2cm Soft dome type Impedance… 4Ω Maximum input… 40W Maximum external dimensions… 150 (width) × 293 (height) × 181 (depth) mm (JEITA) * Weight: Approximately 2.5kg x 2 * Speakers are not magnetically shielded.
Content adapted from: @@Source title@@
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email.
Additional specifications and references
| Region | Japan |
|---|
