| Name | SD-FX1 |
|---|---|
| Manufacturer | Sharp |
| Released | 2001/01 |
| Device type | bookshelf |
| Recorder | Recorder |
| MDLP | Yes |
| NetMD | No |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | 442 x 284 x 182mm |
| Weight | 6.1kg |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | No |
| Voltage | 100 |
| Power cable | AC |
| Price (launch) | Not recorded |
| ¥55 000 | |
| - | |
| Inputs | RCA in, CD, Radio recording |
| Outputs | 3.5mm headphone, Speaker amplifier |
| Control | Not recorded |
Available in SD-FX1-S (Platinum Silver) and SD-FX1-W (Pearl White)
Features: MD/CD/AM/FM, MDLP, 2X CD→MD dubbing, 4-mode multicolor display, 1-bit amplifier samples signals at 2.8 million times per second (64 times that of CD sampling).
Supports CD-Text display.
Specs: 10W (5W+5W) output, 8 cm woofer, 4 cm tweeter, world-band FM radio (76-108MHz), 100VAC.
Content adapted from: Sharp Press Release Sharp Press Release (MiniDisc Wiki mirror) Details Page Details Page (MiniDisc Wiki mirror) Minidisc.org page image source
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email..
Additional specifications and references
| Manual | User manual, other |
|---|---|
| Region | Japan |
