| Name | PCV-MXS5RL7 |
|---|---|
| Manufacturer | Sony |
| Released | 2002/09 |
| Device type | misc |
| Recorder | Recorder |
| MDLP | Yes |
| NetMD | Yes |
| Hi-MD | No |
| Radio | Yes |
| Dimensions | W 192 x H 346 x D 382mm |
| Weight | 11.5kg (body) / 2.8kg (per speaker) |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | Not recorded |
| Voltage | 100 |
| Power cable | Not recorded |
| Price (launch) | Not recorded |
| ¥370 000 | |
| - | |
| Inputs | 3.5mm line in (analog-only), 3.5mm microphone, RCA in, CD |
| Outputs | 3.5mm headphone, RCA out |
| Control | Not recorded |
PCV-MXS5RL5 / PCV-MXS5RL7
The difference between "PCV-MXS5L5" and "MXS5RL7" is the liquid crystal display, the presence or absence of RoomLink, and the specifications of the amplifier. Other specifications are almost the same.
16x speed (LP2) 32x speed (LP4)
- CPU: Intel Pentium 4 Processor 2.40B
- chipset: SiS651 chipset
- Main memory (standard/maximum): 256MB/1.5GB *3 (DDR SDRAM, DDR266 compatible)
- Graphic Accelerator: Built in SiS 651 chipset 32MB (main memory shared)
- hard disk drive: About 120GB (Ultra ATA/100) C drive about 20GB/D drive about 95GB
- Audio: Sony Digital Audio System
Content adapted from: Sony Product Page Spec Page Sony Press Annoucement pc.watch
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email..
Additional specifications and references
| Web Md | Suspected supported |
|---|---|
| Manual | |
| Region | Japan |
