Device

Sony PCV-MXS7L5

Source reference · needs review · MiniDisc Wiki, September 2026 snapshot · Source edited 2023-12-08

Manufacturer
Sony
Model / source grouping
PCV-MXS7L5
Device type
misc
MDLP modes
Yes
NetMD interface
Yes
Hi-MD support
No

Capabilities above are source-stated. USB transfer direction, software requirements and regional variants need separate checks.

Manuals & documentation

Search documentation

No directly linked document has been identified for this record. Search the manual library or consult the source below.

Preserved source

Original source · Source edits are not technical review dates. Original credits and licence notes remain below.

Source: MiniDisc Wiki contributors · September 3, 2026 snapshot · CC BY 4.0, except where otherwise credited.

Attribution and changes

Adapted from “Sony PCV-MXS7L5”. Links, layout and file names normalized; missing database fields restored; remote embeds replaced with links. Manufacturer manuals and separately credited photographs retain their original attribution.


Name PCV-MXS7L5
Manufacturer Sony
Released 2003/02
Device type misc
Recorder Recorder
MDLP Yes
NetMD Yes
Hi-MD No
Radio Yes
Dimensions Width 192 x Height 346 x Depth 382
Weight 11500
ATRAC ver Not recorded
Battery Not recorded Not recorded
Battery notes Not recorded
Sidecar (depr) Not recorded
Voltage 100
Power cable Not recorded
Price (launch) Not recorded
Not recorded
-
Inputs 3.5mm line in (analog-only), CD
Outputs Not recorded
Control Not recorded
  • OS: Microsoft Windows XP Home Edition
  • processor: Intel Pentium 4 Processor 2.53 GHz
  • chipset: SiS651 chipset
  • Main memory (standard/maximum) 256MB/1.0GB 2 slots (DDR SDRAM, DDR333 compatible)
  • graphics accelerator: Built in SiS 651 chipset
  • video memory: 32MB (main memory shared)
  • hard disk drive: Approximately 160GB (Ultra ATA/100)
  • MPEG2 real -time encoder board
  • sound chip: Sony Digital Audio System
  • MD drive: Recordable MD drive for music *16 (Net MD compatible, slot-in mechanism)
  • Max. 32x speed (LP4) Max 16x speed (LP2)

Content adapted from: Sony Product Page Spec Page inversenet.co.jp

Manuals

Repair

Photos

Have photos or data to add? Edit the page! We do not accept contributions via email..

Additional specifications and references
Web MdSuspected supported
Manual
RegionJapan
