| Name | XM-V1-N |
|---|---|
| Manufacturer | Victor |
| Released | 1996/03 |
| Device type | deck |
| Recorder | Recorder |
| MDLP | No |
| NetMD | No |
| Hi-MD | No |
| Radio | No |
| Dimensions | Not recorded |
| Weight | Not recorded |
| ATRAC ver | Not recorded |
| Battery | Not recorded Not recorded |
| Battery notes | Not recorded |
| Sidecar (depr) | Not recorded |
| Voltage | 100 |
| Power cable | Not recorded |
| Price (launch) | Not recorded |
| ¥168 000 | |
| - | |
| Inputs | Not recorded |
| Outputs | Not recorded |
| Control | Not recorded |
The same system was sold in Japan under the Victor brand name and the system was simply called HMV (His Masters Voice). The model names were also different: AX-V1 amplifier, XL-V1-N cd player, TD-V1-N cassette deck and SX-V1A-M compact loudspeaker. Additionally there was available the SX-V7-M floorstander loudspeaker, QL-V1-M Quartz Direct Drive turntable and a later introduced and very rare MD-recorder the XM-V1-N.
1. Thorough "20-bit digital" configuration from the entrance to the exit Equipped with digital/analog conversion and digital input/output that maximizes the 20-bit input/output of the ATRAC IC at the heart
・20-bit 128 times oversampling 1-bit A/D converter installed ・20-bit digital Input /output Equipped with 20bit DD converter
2. Adopting "5 block construction" and "2 power transformers" that thoroughly suppresses mutual interference between digital and analog and realizes advanced musicality ・Digital part / digital signal processing part / analog part / display & system control Interference-free layout Digital and analog dedicated power transformers installed
3. Equipped with 2 systems of digital input corresponding to 3 sampling frequencies ・Equipped with digital input capable of recording a wide range ・Equipped with 2 systems of digital input and multiple digital source devices can be connected
<Other features>
1. Copper plated chassis2 . 3. High rigidity "arc shell chassis" . Extension shaft type recording volume that achieves the shortest signal path design 4. 3-point foot and power transformer placed directly above the foot 5. ６．Extremely thick mechanical stand made of machined brass . All Discrete Lineout Buffer7 . 8. The FL display can be turned on/off with the remote control . Katakana character input/display & multi-jog dial9 . Easy and reliable My Disk editing function. Equipped with 5 editing functions
Content adapted from: Victor Press Release Victor Press Release (MiniDisc Wiki mirror) Victor XM-V1-N
Manuals
Repair
Photos
Have photos or data to add? Edit the page! We do not accept contributions via email.
Additional specifications and references
| Web Md | No (not NetMD) |
|---|---|
| Manual | |
| Region | Japan |
